Fast Series FAH25/1 X 34D

FAST FAH25
The All-in-One day & night scope for Every Mission. With versatile image modes, high refresh rates, and superior thermal sensor quality, it's your reliable, precise, and rugged companion. Elevate your shooting experience with Fast FAH25.

INTRODUCTION:
The INFITAC Fast Series scopes, models FAH25 and FAL19, merge thermal imaging with red dot. Both models operate at a 50Hz refresh rate, with the FAH25 featuring a 640×512 resolution thermal sensor and the FAL19 at 384×288. They include sharp 25mm and 19mm F1.0 lenses respectively. Built tough, each is IP67 waterproof and withstands up to 1200g of recoil.

INNOVATION & CAPABILITIES
- Thermal+Red dot Fusion Tech
- 50 Hz Overlay Refresh Rate
- Modes: Red Dot, Thermal, Outline, Highlight
- Digital Zoom: 1x, 2x
- Multi Reticle & Color Palettes System
- Parallax Free
Compare
SPECIFICATION & COMPARISON
Comparison of specifications between FAH25 and FAL19




1x
1x
1.3x1inch(34x25mm)
1.3x1inch(34x25mm)
3.5inch(90mm)
3.5inch(90mm)
640x512/12μm
384x288/12μm
≤ 18mK
≤ 20mK
50Hz
50Hz
25 F1.0
19 F1.0
17.5x14
13.8x10.4
92x74
68x55
5yds~∞
5yds~∞
0.6inch 800x6000 High luminance OLED
0.6inch 800x6000 Highluminance OLED
1x, 2x
1x, 2x
2xCR123
2xCR123
Thermal mode>4h, Red dot mode>65h
Thermal mode>4h, Red dot mode>65h
Type C, 5V
Type C, 5V
IP67, 33ft. (10 m) depth
IP67, 33ft. (10 m) depth
-40~+122F(-40~+50°C)
-40~+122F(-40~+50°C)
≤240z(680g)
≤23.3oz(660g)
≤6.9x2.5x4.1"
(175x63x104mm)
≤6.9x2.5x4.1"
(175x63x104mm)
